  Block Upconverters (BUCs)    View List:  1 2 3 4 5 6 7 8 9 10
   C-Band
   X-Band
   Low Ku-Band
 Ku-Band
   DBS-Band
   Ka-Band

ABC200KX/ABC200KXF

 ABC200KX/ABC200KXF - 200W Ext. Ku-Band Block Up Converter
  Untitled Model

This unit features:

Output frequency 13.75-14.50 GHz

Based on GaN technology which enables high efficiency, low energy consumption and high reliability

Double - L.O. (switchable 12.80 and 13.05 GHz)

Extreme P-Out GaN linearity (50.6 dBm)

Auto-ranging power 36 ~ 60 VDC power options

Incomparable low power consumption (1174W max)

Digital temperature compensation

L.O. lock and Amplifier LEDs

Digital temperature compensation

Field-exchangeable (F/N) IF connector

M&C - combined RS-232/485/ and Optional FSK

Internal 10 MHz high stability reference (optional)

Ethernet control (HTTP and SNMP ver.3)

RoHS compliant

Model

RF Frequency

Local Frequency

IF Frequency

Output Power

Connector

ABC200KX

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

200W (+53.2 dBm min.)

N-type

ABC200KXF

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

200W (+53.2 dBm min.)

F-type

Block Upconverters (BUCs)  /  Ku-Band   Manufacturer: Actox
Availability:  Contact Us

Price:  Contact Us
   Product details    Download full description in format
ABD250KX/ABD250KXF

 ABD250KX/ABD250KXF - 250W Extended Ku-Band Block Up Converter
  Untitled Model

This unit features:

Output frequency 13.75-14.50 GHz

Based on GaN technology which enables high efficiency, low energy consumption and high reliability

Double - L.O. (switchable 12.80 and 13.05 GHz)

Extreme P-Out GaN linearity

Auto-ranging power 196-265 VAC power options

Incomparable low power consumption (1140W max)

Digital temperature compensation

L.O. lock and Amplifier LEDs

Digital temperature compensation

Field-exchangeable (F/N) IF connector

M&C - combined RS-232/485, Ethernet Control (HTTP and SNMP ver. 3) and optional FSK

Internal 10 MHz high stability reference (optional)

Ethernet control (optional)

RoHS compliant

Model

RF Frequency

Local Frequency

IF Frequency

Output Power

Connector

ABD250KX

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

250W (+54 dBm min.)

N-type

ABD250KXF

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

250W (+54 dBm min.)

F-type

Block Upconverters (BUCs)  /  Ku-Band   Manufacturer: Actox
Availability:  Contact Us

Price:  Contact Us
   Product details    Download full description in format
ABD300KX/ABD300KXF

 ABD300KX/ABD300KXF - 300W Ext. Ku-Band Block Up Converter
  Untitled Model

This unit features:

Output frequency 13.75-14.50 GHz

Based on GaN technology which enables high efficiency, low energy consumption and high reliability

Double - L.O. (switchable 12.80 and 13.05 GHz)

Extreme P-Out GaN linearity

Auto-ranging power 196-265 VAC power options

Incomparable low power consumption (1675W max)

Digital temperature compensation

L.O. lock and Amplifier LEDs

Digital temperature compensation

Field-exchangeable (F/N) IF connector

M&C - combined RS-232/485, Ethernet Control (HTTP and SNMP ver. 3) and optional FSK

Internal 10 MHz high stability reference (optional)

Ethernet control (optional)

RoHS compliant

Model

RF Frequency

Local Frequency

IF Frequency

Output Power

Connector

ABD300KX

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

300W (+54.8 dBm min.)

N-type

ABD300KXF

13.75 to 14.50 GHz

12.80 & 13.05 GHz

950 to 1,700 MHz

300W (+54.8 dBm min.)

F-type

Block Upconverters (BUCs)  /  Ku-Band   Manufacturer: Actox
Availability:  2-3 weeks

Price:  Contact Us
   Product details    Download full description in format
