This unit features:

Smallest and lightest

Double - L.O. (electronically switchable 12.80/13.05GHz)

Auto-ranging 18-75 VDC power option

Low power consumption (<82W)

Digital temperature compensation

“Cooling fan” solution

L.O. lock and amplifier LED

14.00-14.50/13.75-14.50 GHz capability

M&C - combined RS-232/485/FSK (optional)

Three-year warranty

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABE8KFX	13.75 to 14.50 GHz	12.80 & 13.05 GHz	950 to 1,700 MHz	8W (+39 dBm min.)	N-type
ABE8KFXF	13.75 to 14.50 GHz	12.80 & 13.05 GHz	950 to 1,700 MHz	8W (+39 dBm min.)	F-type

This unit features:

No “cooling fan” solution

High efficiency output power (10W minimum @ P1dB over temperature)

Three power supply selections:

DC: +48 VDC operation (+38 to +60 VDC)

DC: +24 VDC operation (+18 to +36 VDC)

Option: separation of power supply port (MS-connector)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABA10KU	14.00 to 14.50 GHz	13.05 GHz	950 to 1,450 MHz	10W (+40 dBm min.)	N-type
ABA10KUF	14.00 to 14.50 GHz	13.05 GHz	950 to 1,450 MHz	10W (+40 dBm min.)	F-type

This unit features:

No “cooling fan” solution

High efficiency output power (10W minimum @ P1dB over temperature)

Three power supply selections:

DC: +48 VDC operation (+38 to +60 VDC)

DC: +24 VDC operation (+18 to +36 VDC)

Option: Separation of power supply port (MS-connector)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABA10KUL	13.75 to 14.25 GHz	12.80 GHz	950 to 1,450 MHz	10W (+40 dBm min.)	N-type
ABA10KULF	13.75 to 14.25 GHz	12.80 GHz	950 to 1,450 MHz	10W (+40 dBm min.)	F-type

This unit features:

No “cooling fan” solution

High efficiency output power (10W minimum @ P1dB over temperature)

Three power supply selections:

DC: +48 VDC operation (+38 to +60 VDC)

DC: +24 VDC operation (+18 to +36 VDC)

Option: separation of power supply port (MS-connector)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABA10KUX	13.75 to 14.50 GHz	12.80 GHz	950 to 1,700 MHz	10W (+40 dBm min.)	N-type
ABA10KUXF	13.75 to 14.50 GHz	12.80 GHz	950 to 1,700 MHz	10W (+40 dBm min.)	F-type

This unit features:

High efficiency output power (10W minimum @ P1dB over temperature)

Three power supply selections:

Option 1: +18 VDC~+24 VDC via IF cable

Option 2: +38 VDC~+60 VDC via IF cable

Option 3: +38 VDC~+60 VDC via MS conn

Option: Separation of power supply port (MS-connector)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABAN10KU	14.00 to 14.50 GHz	13.05 GHz	950 to 1,450 MHz	8W (+40 dBm min.)	N-type
ABAN10KUF	14.00 to 14.50 GHz	13.05 GHz	950 to 1,450 MHz	10W (+40 dBm min.)	F-type
