This unit features:

Field-exchangeable (F/N) IF connector

High Efficiency Output Power (12W minimum @ P1dB over temperature)

DC: 24/48Vdc (18-75 Vdc)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABE12FXC	5.85 to 7.2 GHz	4.90 & 5.50GHz	950 to 1,700 MHz	12W (+41 dBm min.)	N-Type
ABE12FXCF	5.85 to 7.2 GHz	4.90 & 5.50GHz	950 to 1,700 MHz	12W (+41 dBm min.)	F-Type

This unit features:

No “cooling fan” solution

High efficiency output power (12W minimum @ P1dB over temperature)

Three power supply selections:

DC:+24 VDC operation (+18 to +36 VDC)

DC:+48 VDC operation (+36 to +52 VDC)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABA12C	5.850 to 6.425 GHz	4.90 GHz	950 to 1,525 MHz	12W (+41 dBm min.)	N-type
ABA12CF	5.850 to 6.425 GHz	4.90 GHz	950 to 1,525 MHz	12W (+41 dBm min.)	F-type

This unit features:

No “cooling fan” solution

High efficiency output power (12W minimum @ P1dB over temperature)

Three power supply selections:

DC:+24 VDC operation (+18 to +36 VDC)

DC:+48 VDC operation (+36 to +52 VDC)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABA12CP	6.425 to 6.725 GHz	5.275 GHz	1,150 to 1,450 MHz	12W (+41 dBm min.)	N-type
ABA12CPF	6.425 to 6.725 GHz	5.275 GHz	1,150 to 1,450 MHz	12W (+41 dBm min.)	F-type

This unit features:

No “cooling fan” solution

High efficiency output power (15W minimum @ P1dB over temperature)

Three power supply selections:

DC:+24 VDC operation (+18 to +36 VDc)

DC:+48 VDC operation (+36 to +52 VDC)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABA15C	5.850 to 6.425 GHz	4.90 GHz	950 to 1,525 MHz	15W (+41.8 dBm min.)	N-type
ABA15CF	5.850 to 6.425 GHz	4.90 GHz	950 to 1,525 MHz	15W (+41.8 dBm min.)	F-type

This unit features:

No “cooling fan” solution

High efficiency output power (15W minimum @ P1dB over temperature)

Three power supply selections:

DC:+24 VDC operation (+18 to +36 VDC)

DC:+48 VDC operation (+36 to +52 VDC)

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABA15CP	6.425 to 6.725 GHz	5.275 GHz	1,150 to 1,450 MHz	15W (+41.8 dBm min.)	N-type
ABA15CPF	6.425 to 6.725 GHz	5.275 GHz	1,150 to 1,450 MHz	15W (+41.8 dBm min.)	F-type
