This unit features:

High efficiency output power (50W minimum @ P1dB over temperature)

Double - L.O. (electronically switchable 4.90/5.5GHz)

Auto-ranging 38-56 VDC via MS connector input

5.875-7.200 GHz capability

“Cooling fan” solution

Advanced M&C - combined RS-232/485

FSK (optional)

Smallest package size and weight

RoHS compliant

L.O. lock and amplifier LED

For the complete description please see the pdf file below.

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABC50XC	5.875 to 7.200 GHz	4.90 & 5.5 GHz	950 to 1,700 MHz	50W (+47 dBm min.)	N-type
ABC50XCF	5.875 to 7.200 GHz	4.90 & 5.5 GHz	950 to 1,700 MHz	50W (+47 dBm min.)	F-type

This unit features:

High efficiency output power (50W minimum @ P1dB over temperature)

Double - L.O. (electronically switchable 4.90/5.5GHz)

Auto-ranging 80-240VAC via MS connector input

5.875-7.200 GHz capability

“Cooling fan” solution

Advanced M&C - combined RS-232/485

FSK (optional)

Smallest package size and weight

RoHS compliant

L.O. lock and amplifier LED

For the complete description please see the pdf file below.

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABD50XC	5.875 to 7.200 GHz	4.90 & 5.5 GHz	950 to 1,700 MHz	50W (+47 dBm min.)	N-type
ABD50XCF	5.875 to 7.200 GHz	4.90 & 5.5 GHz	950 to 1,700 MHz	50W (+47 dBm min.)	F-type

This unit features:

High efficiency output power (50W minimum @ P1dB over temperature)

Smallest package size and weight

80-240 VAC autoranging via MS connector input

RoHS compliant

Power and lock status LED

For the complete description please see the pdf file below.

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABD50DC	5.850 to 6.725 GHz	4.90 GHz	950 to 1,825MHz	50W (+47 dBm min.)	N-type
ABD50DCF	5.850 to 6.725 GHz	4.90 GHz	950 to 1,825MHz	50W (+47 dBm min.)	F-type

This unit features:

High efficiency output power (50W minimum @ P1dB over temperature)

Smallest package size and weight

38-56 VDC autoranging via MS connector input

RoHS compliant

Power andl lock status LED

For the complete description please see the pdf file below.

Model	RF Frequency	Local Frequency	IF Frequency	Output Power	Connector
ABC50DC	5.850 to 6.725 GHz	4.90 GHz	950 to 1,825 MHz	50W (+47 dBm min.)	N-type
ABC50DCF	5.850 to 6.725 GHz	4.90 GHz	950 to 1,825 MHz	50W (+47 dBm min.)	F-type
